FEATURES
30 AH battery 5600w 85KM/H HIGH SPEED
IP54 Waterproof
13-inch Off-road Tires
Strong grip, wear-resisting and safe. It’s suitable for different kinds of roads.
60V 30Ah Hug Capacity Battery
It is more durable with 30Ah high capacity battery.
2800W x2 motor
Strong power and running farther: 2800W x2 motor, maximum speed up to 85km/h.
Specification
Brand: OBARTER
Model: X5
Max Speed(km/h) 85km/h
Speed Mode
1. 35KM/H;
2. 65KM/H;
3. 85KM/H
Max Range(KM) up to 65km – 75km
Working Temperature -20?C – 100?C
Max Slope: 55?C
Cruise Control Function(CCS): Yes
Brake Type: Oil Disk Brake
Waterproof: IP54
Material: Iron + Aluminium
Package Size(mm) 1510*380*620
Unfolded Size (mm) 1340*700*1430
Folded Size(mm) 1520*370*570
Net. Weight(KG) 56.2kg
Gross Weight(KG) 62.5kg
Max Load(KG) 120kg
vibration reduction
Front hydraulic damping; Rear Spring shock absorption
Motor Rate Voltage(V) 60V
Motor Rate Power(W) 2800W x2
Motor Rate Current(A) 13A
Motor Non-Load Current(A) 2.1A
Motor Non-Load PR(1min) 1650
Qty of Motor 2
Motor Size(mm) 180mm
Front Wheer Size(mm) 320mm
Rear Wheel Size(mm) 320mm
Battery Capacity(AH) 30Ah
Battery Rate Voltage(V) 60V
Battery Rate Power(W) 1800
Battery Input Rate Voltage(V) 67.2
Battery BMS: Yes
Battery Charging Time(H) 11
Charger Rate Input Voltage(V) 100-240V
Charger Rate Output Voltage(V) 67.2V(?1.5V)
Charger Rate Current(A) 2.0A (?0.2A)
Charger Working Voltage(V) 50V – 67.2V
Type of Display: LCD
Certification CE, FCC, ROHS
Package contents
1 x Scooter
1 x Charger
1 x Tool bag
1 x User manual
